Meraki MS250-48FP Kenya

The Cisco Meraki MS250-48FP Kenya is a 24-port cloud-managed stackable enterprise-class access switch with four SFP+ uplinks. It offers support for redundant power supplies for mission critical environments, and IP routing. Meraki MS250-48FP includes integrated client and layer 7 application visibility

Add to quote

Description

Meraki MS250-48FP Network Switch Kenya

The Meraki MS250-48FP Kenya is a 24-port cloud-managed stackable enterprise-class access switch with four SFP+ uplinks, support for redundant power supplies for mission critical environments, and IP routing. Meraki MS250-48FP Kenya includes integrated client and layer 7 application visibility, remote troubleshooting tools like live packet capture and cable test. Meraki Network Switch Kenya is fully cloud-managed via the intuitive, browser-based Meraki dashboard, and includes a rich, out-of-the-box feature for easy configuration and provisioning without need of additional cost and complexity.

The Meraki MS250-48FP Switch Kenya provide reliable access switching ideal for deploying in branches and small campuses. With stacking capabilities and 10G SFP+ uplinks on every model, redundancy and performance are guaranteed. Meraki MS250-48FP also supports redundant, field-replaceable power supplies for mission-critical networks. Meraki switches are built from the ground up to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.

MS250-48FP Features

Gigabit access switching with 24- and 48- port models and optional PoE+ support
4 x 10G SFP+ uplink interfaces on all models
Dual stacking interfaces with up to 80G of bandwidth
Support for field replaceable, redundant power supplies
Non-blocking switch backplane with up to 176 Gbps of switching capacity
6 configurable QoS queues for converged voice, video, and data applications
Up to 740 watt PoE budget with PoE+ support and dynamic power allocation for powering APs, phones, cameras, and other PoE-enabled devices
Low power consumption, quiet acoustic design, and shallow rack depth options, enabling flexible deployment in wiring closets as well as offices and classrooms
Integrated mounting brackets for rack mounting
Lifetime hardware warranty and advanced replacement at no additional cost

Centrally managed from the cloud

The Meraki Cloud Networking architecture enables Plug and Play branch deployments and provides centralized visibility and control across any number of distributed locations. The Meraki MS250-48FP Kenya is the industry’s cloud managed switch, combining the benefits of cloud-based centralized management with a powerful, reliable access platform. With cloud management, thousands of switch ports can be configured and monitored instantly, over the web. Provision remote sites without on-site IT, deploy network-wide configuration changes, and easily manage campus and distributed networks without training or dedicated staff.

Layer 7 application and client visibility

Meraki MS250-48FP Kenya features integrated Layer 7 application and client fingerprinting and analysis. Hundreds of applications are automatically identified and reported, from business apps to BitTorrent and YouTube, so administrators can see where resources are spent.

QoS for voice and video

Deploy latency-sensitive applications such as voice and video by guaranteeing network performance. Voice and QoS features such as per-VLAN and protocol-based prioritization, as well as flexible QoS assignments, give intuitive, granular control.

Enterprise security

Extending security down to the port level has never been easier. Meraki MS250-48FP Kenya integrate seamlessly with enterprise-grade security systems using 802.1x. Define access policies, segregate guest devices, and quarantine entire environments right from the dashboard.

MS250-48FP Specifications

Dimensions and Interfaces

Physical Dimensions (H x W x D): 1.72 x 19.08 x 20.42” (4.38 x 48.46 x 51.87cm)
Weight:12.83 lb (5.82 kg)
Interface: 48 x 10/100/1000BASE-T Ethernet RJ45 with auto negotiation and crossover detection (auto-MDIX crossover) 4 x SFP+ 10GbE uplink, 2 x stacking ports
Switching Capacity:176 Gbps
Stacking Bandwidth: 80G (dual interface)

Power Options and Specifications

Idle / Full Load Power: 25 / 874 W
Available PoE+ Power: 740 W
Power Supply Configuration: Hot-swappable
Supported Power Supply:2 x 1025W PSU

Management

Managed via the Web with the Meraki cloud management platform
Integrated with Meraki Wireless and complete portfolio of IT products and solutions
Zero-touch remote provisioning (no staging needed)
Detailed historical per-port and per-client usage statistics
DHCP, client, and hostname fingerprinting
SNMP and SYSLOG support for integration with other network management solutions
Automatic firmware upgrades with scheduling control

Remote Diagnostics

Email, SMS and Mobile push notification alerts
Cable testing and link failure detection with alerting
Live remote packet capture
Dynamic and interactive network discovery and topology
Combined event and configuration change logs with instant search

Stacking

Physical stacking of up to 8 switches with 80 Gbps stack bandwidth on all models
Virtual Stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration

Ethernet Switching Capabilities

802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping)
802.1Q VLAN and trunking support for up to 4,094 VLANs
802.1w, 802.1D Rapid Spanning Tree Protocol (RSTP, STP)
Broadcast storm control
802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP)
802.3ad Link aggregation with up to 8 ports per aggregate, Multi-chassis aggregates supported on stacked switches
Port mirroring
IGMP snooping for multicast filtering
MAC forwarding entries : 16K on 24-port models, 32K on 48-port models

Security
