Cisco ISR4431 Kenya



Cisco ISR4431 Kenya

Cisco ISR4431 Kenya Integrated Service Router is highly-available architecture designed router for mission-critical branches delivering high-speed, predictable performance and modularity to connect from most remote locations.

Description

Cisco ISR4431 Integrated Service Router Kenya

Cisco ISR4431 Kenya Integrated Service Router is highly-available architecture designed router for mission-critical branches delivering high-speed, predictable performance and modularity to connect from most remote locations. The Cisco ISR4431 Kenya Integrated Service Router, provides routing, hosting, security, and switching in a single, trustworthy platform. The Router also packs latest technologies, from SD-WAN to edge computing, while meeting the explosive network-performance needs driven by cloud applications and digital transformation.

The Cisco ISR4431 Kenya Integrated Service Router revolutionizes WAN communications in the enterprise branch. With new levels of built-in intelligent network capabilities and convergence, it specifically addresses the growing need for application-aware networking in distributed enterprise sites. These locations tend to have lean IT resources. But they often also have a growing need for direct communication with both private data centers and public clouds across diverse links, including Multiprotocol Label Switching (MPLS) VPNs and the Internet. Moreover, deploy key integrated network services for your branch in minutes, virtually or on-premises, without sacrificing performance. Configure and monitor your network and enforce business policies through Cisco DNA Center and Cisco SD-WAN. Simplify network automation and turn hours of work into minutes.

Features

Threat protection

Cisco ISR4431 Kenya Router protects your branch site across the LAN and WAN and in the cloud with security integrated into the router. You no longer need a separate security appliance.

Cisco Software Defined WAN

Cisco SDWAN is a set of intelligent software services that allow you to reliably and securely connect users, devices, and branch office locations across a diverse set of WAN transport links. SDWAN-enabled routers like the ISR 4000 dynamically route traffic across the “best” link based on up-to-the-minute application and network conditions for great application experiences. You get tight control over application performance, bandwidth usage, data privacy, and availability of your WAN links – control that you need as your branches conduct greater volumes of mission-critical business.

Cisco Converged Branch Infrastructure

The Cisco ISR4431 Kenya consolidates many must-have IT functions, including network, compute, and storage resources. The high-performance, integrated routers run multiple concurrent services, including encryption, traffic management, and WAN optimization, without slowing your data throughput. And you can activate new services on demand through a simple licensing change.

Cisco Intent Based Networking and Digital Network Architecture (Cisco DNA)

The Cisco Digital Network Architecture (Cisco DNA) is an open, extensible, software-driven architecture that provides for faster innovation, helping to generate deeper insights, and deliver exceptional experiences across many different applications. Cisco DNA relies on intent-based networking, a revolutionary approach in networking that helps organizations automate, simplify, and secure the network.

Throughput & Service reliability

  • Concurrent software services at speeds up to 2 Gbps. Backplane architecture supports high-bandwidth module-to-module communication at speeds up to 10 Gbps.
  • A distributed multicore architecture with the industry’s first internal services plane.
  • Remote installation of application-aware services, which run identically to their counterparts in dedicated appliances.

Lower WAN expenditures

Cisco ISR4431 Kenya has embedded SDWAN solution for creating lower-cost, business-class Internet connections.

Performance upgrade model, Investment protection as CapEx budget management

  • Router capacity can be increased with a remote performance-on-demand license upgrade (no hardware upgrade) for exceptional savings.

Cisco ISR4431 Kenya has Superior and secure user application experiences

  • ISR-AX “Application Experience” software bundle with advanced routing and network monitoring services.
  • Dynamic Multipoint VPN (DMVPN), zone-based firewalls, Intrusion Prevention (Snort & Umbrella Branch) and Content Management using Cisco Cloud Web security & OpenDNS protecting data, providing authentication credentials, and transmissions not backhauled through the data center.
  • Secure boot feature performs hardware-based authentication of the bootloader software to prevent malicious or unintended software from booting on the system.
  • Code signing verifies digital signatures of executables prior to loading to prevent execution of altered or corrupted code.
  • Hardware authentication protects against hardware counterfeiting by using an on-board tamper-proof silicon, including field replaceable modules. If authentication fails, the module is not allowed to boot

IT consolidation, space savings, and improved Total Cost of Ownership (TCO)

Single converged branch platform integrates routing, switching, virtual server, storage, security, unified communications, WAN optimization, and performance management tools.

Business continuity and increased resiliency

  • Cisco ISR4431 Kenya support dual integrated power supplies for backup. Also the router supports optional power supply capable of delivering additional PoE power to endpoints.
  • Modular network interfaces with diverse connection options for load-balancing and network resiliency.
  • Modular interfaces with online removal and insertion (OIR) for module upgrades without network disruption.
  • Cisco Unified Survivable Remote Site Telephony (SRST), which serves as a resiliency complement to Cisco Hosted Collaboration Solution (HCS), a Cisco cloud-based UC service.
  • Support for multiple, diverse access links: T1/E1, T3/E3, Serial, xDSL, Gigabit and Ten-Gigabit Ethernet.

Lower telephony costs with VoIP and rich media experiences

  • High-performance analog/digital gateway, allowing VoIP over less expensive Session Initiation Protocol (SIP) trunks.
  • Integrated IP PBX (Cisco Unified Communications Express) and Session Border Controller (Cisco Unified Border Element, or CUBE).

Easier manageability and support

  • Single, universal software image for all features and performance-on-demand licensing flexibility.
  • Cisco ISR4431 Kenya require no additional services and support needed for compute and storage.
  • Cisco ISR4431 Kenya is supported by Cisco and third-party management tools, with programmability and automation.

Specifications

Model Cisco 4461 Cisco 4431 Cisco 4331 Cisco 4221
Aggregate Throughput (Default) 1.5Gbps 500 Mbps 100 Mbps 35Mbps
Aggregate Throughput (Performance License) 3Gbps 1Gbps 300 Mbps 75 Mbps
Aggregate CEF Only1 Throughput (Boost License) Over 7Gbps Over 4Gbps Over 2Gbps 1.2Gbps
Total onboard WAN or LAN 10/100/1000 ports 4 4 3 2
Total onboard WAN or LAN 10Gbps ports 2
RJ-45-based ports 4 4 2 2
SFP-based ports 4 4 2 1
Enhanced service-module slots 3 0 1 0
Doublewide service-module slots 2 0 0 0
NIM slots 3 3 2 2
OIR (all I/O modules) Yes Yes Yes No
Onboard ISC slot 1 1 1 No
Default memory double-data-rate 3 (DDR3) errorcorrection-code (ECC) DRAM (Combined control/services/d ata planes) NA NA 4GB 4GB
Maximum memory DDR3 ECC DRAM (Combined control/services/d ata planes) NA NA 16GB 4GB
Default memory DDR3 ECC DRAM (data plane) 4 GB 2 GB NA NA
Maximum memory DDR3 ECC DRAM (data plane) 4 GB 2 GB NA NA
Default memory DDR3 ECC DRAM (control/services plane) 8 GB 4 GB NA NA
Maximum memory DDR3 ECC DRAM (control/services plane) 32 GB 16 GB NA NA
Default flash memory 8 GB 8 GB 4 GB 8 GB
Maximum flash memory 32 GB 32 GB 16 GB 8 GB
External USB 2.0 slots (type A) 2 2 1 1
USB console port -type B mini (up to 115.2 kbps) 1 1 1 0
Serial console port – RJ45 (up to 115.2 kbps) 1 1 1 1 (combo CON/AUX port)
Serial auxiliary port – RJ45 (up to 115.2 kbps) 1 1 1 1 (combo CON/AUX port)
Power-supply options Internal: AC, DC and PoE Internal: AC, DC and PoE Internal: AC, DC, and PoE External AC only
Redundant power supply Internal: AC, DC and PoE Internal: AC, DC and PoE N/A N/A
Power Specifications
AC input voltage 100 to 240 VAC autoranging 100 to 240 VAC autoranging 100 to 240 VAC autoranging 100 to 240 VAC autoranging
DC Input Voltage
Input Voltage
Input Current
48 – 60V
12A Max
48 – 60V
12A Max
24 – 60V
14 – 5A
NA
NA
AC input frequency 47 to 63 Hz 47 to 63 Hz 47 to 63 Hz 47 to 63 Hz
AC input current range, AC power supply (maximum) 7.1 to 3.0A 3 to 1.3A 3 to 1.3A 1.5 to 0.6A
Sizes and Weights
Dimensions (H x W x D) 3.5 x 17.25 x 18.5 in
88.9 x 438.15 x 469.9 mm)
1.73 x 17.25 x 19.97 in
(43.9 x 438.15 x 507.2 mm)
1.75 x 17.25 x 17.25 in
(44.45 x 438.15 x 438.15 mm)
1.72 x 12.7 x 10 in
(43.7 x 322.6 x 254 mm)
Wall-mount No Yes Yes Yes
Typical weight (fully loaded with modules) 22.4 lb (10.2 kg) 16.1 lb (7.3 kg) 8.11 lb (3.68kg)
MTBF (Hours) 480770 512970 587250 593270
Environmental Specifications
Operating Conditions
Temperature 32 to 104ºF (0 to 40ºC) 32 to 104ºF (0 to 40ºC) 32 to 104ºF (0 to 40ºC) 32 to 104ºF (0 to 40ºC)
Relative humidity 5% to 85% 5% to 85% 5% to 85% 5% to 85%
Nonoperating Conditions
Temperature -40 to 158ºF
(-40 to 70ºC)
-40 to 158ºF
(-40 to 70ºC)
-40 to 158ºF
(-40 to 70ºC)
-40 to 158ºF
(-40 to 70ºC)
Relative humidity 5% to 95% 5% to 95% 5% to 95% 5% to 95%
Cisco IOS XE Software
Protocols IPv4, IPv6, static routes, Routing Information Protocol Versions 1 and 2 (RIP and RIPv2), Open Shortest Path First (OSPF), Enhanced IGRP (EIGRP), Border Gateway Protocol (BGP), BGP Router Reflector, Intermediate System-toIntermediate System (IS-IS), Multicast Internet Group Management Protocol Version 3 (IGMPv3), Protocol Independent Multicast sparse mode (PIM SM), PIM Source Specific Multicast (SSM), RSVP, CDP, ERSPAN, IPSLA, Call Home, EEM, IKE, ACL, EVC, DHCP, FR, DNS, LISP, OTV6, HSRP, RADIUS, AAA, AVC, Distance Vector Multicast Routing Protocol (DVMRP), IPv4-to-IPv6 Multicast, MPLS, Layer 2 and Layer 3 VPN, IP sec, Layer 2 Tunneling Protocol Version 3 (L2TPv3), Bidirectional Forwarding Detection (BFD), IEEE802.1ag, and IEEE802.3ah
Encapsulations Generic routing encapsulation (GRE), Ethernet, 802.1q VLAN, Point-to-Point Protocol (PPP), Multilink Point-to-Point Protocol (MLPPP), Frame Relay, Multilink Frame Relay (MLFR) (FR.15 and FR.16), High-Level Data Link Control (HDLC), Serial (RS-232, RS-449, X.21, V.35, and EIA-530), and PPP over Ethernet (PPPoE)
Traffic management QoS, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Hierarchical QoS, Policy-Based Routing (PBR), Performance Routing, and NBAR.
Cryptographic Algorithms Encryption: DES, 3DES, AES-128 or AES-256 (in CBC and GCM modes); Authentication: RSA (748/1024/2048 bit), ECDSA (256/384 bit); Integrity: MD5, SHA, SHA-256, SHA-384, SHA-512
