Description

Cisco Catalyst 9120AX Access Point Kenya

The Cisco Catalyst9120AX Kenya provides integrated security, resiliency, and operational flexibility as well as increased network intelligence. Extending Cisco’s intent-based network and perfect for networks of all sizes, the Cisco Catalyst 9120AX Series scales to the growing demands of IoT while fully supporting the latest innovations and new technologies. Also, this Cisco WiFi Kenya is a leader in performance, security, and analytics. The Cisco Catalyst 9120AX Access Point Kenya, paired with Cisco DNA, features enterprise-class products that will address your current and future needs. Update your network so that you can take better advantage of all of the features and benefits that Wi-Fi 6 provides with this Cisco WiFi Kenya.

Features

Resilient

A Wi-Fi 6/6E-enabled Cisco Catalyst9120AX Kenya gives your network a capacity boost and helps it run efficiently.

Secure

With image signing, secure boot, Cisco Trust Anchor, and more, the Cisco Catalyst9120AX Kenya helps secure your entire network.

Intelligent

Paired with Cisco DNA software, the Cisco WiFi Kenya provides you with Enhanced AI Analytics and more efficiency.

Wi-Fi 6 (802.11ax)

The IEEE 802.11ax emerging standard, also known as High-Efficiency-Wireless (HEW) or Wi-Fi 6, builds on 802.11ac. Cisco Catalyst9120AX Kenya delivers a better experience in typical environments with more predictable performance for advanced applications such as 4K or 8K video, high-density, high-definition collaboration apps, all-wireless offices, and IoT. Wi-Fi 6 is designed to use both the 2.4-GHz and 5-GHz bands, unlike the 802.11ac standard

Cisco RF ASIC

Cisco RF ASIC is a fully integrated Software-Defined Radio (SDR) that can perform advanced RF spectrum analysis and delivers features like Cisco CleanAir, Wireless Intrusion Prevention System (wIPS), Fast Locate, and DFS detection.

Uplink/downlink OFDMA

Orthogonal Frequency-Division Multiple Access (OFDMA)-based scheduling splits the bandwidth into smaller chunks called Resource Units (RUs), which can be allocated to individual clients in both the downlink and uplink directions to reduce overhead and latency.

MU‑MIMO technology

Supporting four spatial streams, Multiuser Multiple Input, Multiple Output (MU-MIMO) enables access points to split spatial streams between client devices, to maximize throughput.

BSS coloring

Spatial reuse (also known as Basic Service Set [BSS] coloring) allows the access points and their clients to differentiate between BSSs, thus permitting more simultaneous transmissions

Target wake time

A new power savings mode called Target Wake Time (TWT) allows the client to stay asleep and to wake up only at prescheduled (target) times to exchange data with the access point. This offers significant 459energy savings for battery-operated devices, up to three to four times greater compared to 802.11n and 802.11ac.

Intelligent Capture

Intelligent Capture probes the network and provides Cisco DNA Center with deep analysis. The software can track over 240 anomalies and instantaneously review all packets on demand, emulating the onsite network administrator. Intelligent Capture allows for more informed decisions on your wireless networks.

Flexible Radio Assignment

Cisco Catalyst9120AX Kenya intelligently determine the operating mode of serving radios based on the RF environment. The access points can operate in the following modes:

• 4-GHz and 5-GHz mode: One radio will serve clients in 2.4-GHz mode, while the other serves clients in 5-GHz mode.
• Dual 5-GHz mode: Both radios inside the access point operate on the 5-GHz band, maximizing the benefits of Wi-Fi 6 and increasing client device capacity

Dual 5-GHz radio support

Cisco WiFi Kenya enables both radios to operate in 5-GHz client serving mode, allowing an industry-leading 5.2 Gbps (2 x 2.6 Gbps) over-the-air speeds while increasing client capacity.

Smart antenna connector

An intelligent second physical antenna connector is included on Cisco Catalyst9120AX Kenya access points with an external antenna. This connector provides advanced network design flexibility for high-density and large open-area environments such as auditoriums, convention centers, libraries, cafeterias, and arenas/stadiums, allowing two sets of antennas to be connected and active on a single access point.

Cisco Embedded Wireless Controller

The Cisco Catalyst9120AX Kenya Wi-Fi 6 access points is available with a built-in controller. The Cisco Embedded Wireless Controller on Catalyst 9100 Access Points provides an easy-to-deploy and manage option that does not require a physical appliance. The control resides on the access point so there is no added footprint or complexity. And, because it uses Cisco Catalyst 9800 Series code, it’s easy to migrate your network as your needs grow

Application Hosting on Catalyst 9100 Access

Application Hosting on Catalyst 9100 Access Points helps future-proof and simplify IoT deployments by eliminating the need to install and manage overlay networks. Utilizing the USB interface, containerized applications and hardware modules can be deployed to reduce cost and complexity. Adding Cisco DNA Center provides workflows and deployment-wide application lifecycle management.

Multigigabit Ethernet support

This Cisco WiFi Kenya provides uplink speeds of 2.5 Gbps, in addition to 100 Mbps and 1 Gbps. All speeds are supported on Category 5e cabling for an industry first, as well as 10GBASE-T (IEEE 802.3bz) cabling.

Bluetooth radio

Integrated Bluetooth Low Energy 5 radio to enable IoT use cases such as location tracking and wayfinding.

Container support for applications

Cisco Catalyst9120AX Kenya enables edge computing capabilities for IoT applications on the host access point.

Apple features

Apple and Cisco have partnered to create an optimal mobile experience for iOS devices on corporate networks based on Cisco technologies. Using new features in iOS 10, in combination with the latest software and hardware from Cisco, businesses can now more effectively use their network infrastructure to deliver an enhanced user experience across all business applications.

Specifications
