Cisco SG550XG-8F8T Kenya



Cisco SG550XG-8F8T Kenya

The Cisco SG550XG-8F8T Kenya stackable managed Ethernet switch, provides the advanced capabilities and superior performance you need to support a more demanding network environment at an affordable price

Category:

Description

Cisco SG550XG-8F8T Network Switch Kenya

The Cisco SG550XG-8F8T Kenya stackable managed Ethernet switch, provides the advanced capabilities and superior performance you need to support a more demanding network environment at an affordable price. The Cisco SG550XG-8F8T Kenya Switch is a next-generation managed switch that offers excellent performance, rich features, and ease of use. With support for Layer 2 and 3 features, advanced security, routing, and energy-saving technology, it delivers a solid foundation for business applications today and in the future. This switch incorporates fan and power hardware redundancy, increasing overall network availability at the same time, Cisco SG550XG-8F8T Kenya switch is easy to deploy and manage, without a large IT staff.

Cisco SG550XG-8F8T Kenya is designed to protect your technology investment as your business grows. Unlike switches that claim to be stackable but have elements that are administered and troubleshot separately, the Cisco SG550XG-8F8T Kenya provides true stacking capability, allowing you to configure, manage, and troubleshoot multiple physical switches as a single device and more easily expand your network. A true stack delivers a unified data and control plane, in addition to a management plane, providing flexibility, scalability, and ease of use because the stack of units operates as a single entity constituting all the ports of the stack members. Cisco SG550XG-8F8T Kenya Switch provides the advanced feature set that growing businesses require and that high-bandwidth applications and technologies demand.

Features

Affordable 10 Gigabit Ethernet

The Cisco SG550XG-8F8T Kenya breaks the barrier of 10 Gigabit Ethernet adoptions with exceptional affordability. 10 Gigabit Ethernet delivers 10 times the performance to your network to promote higher productivity and business efficiency.

Unmatched reliability and resiliency

 The Cisco SG550XG-8F8T Kenya offers true stacking, built-in fan redundancy, a redundant power supply connector, and high-availability protocols. Keep your network running so your business never slows down.

Advanced features

The Cisco SG550XG-8F8T Kenya includes capabilities and management options you need to support applications today and in the future, such as strong security, advanced QoS, comprehensive IPv6 support, and Layer 3 dynamic routing.

Power over Ethernet

The Power over Ethernet Plus (PoE+) standard provides up to 30 watts of power per port. The Cisco SG550XG-8F8T Kenya also support 60W PoE on selected ports to power compact switches and high-power wireless access points.

Energy efficiency

Cisco SG550XG-8F8T Kenya packs a variety of energy-saving features, including energy-detect mode, cable-length detection, and Energy-Efficient Ethernet, provide an eco-friendly and cost-effective network solution without compromising performance.

Specifications

Product Code SG550XG-8F8T
Capacity in mpps (64-byte packets) 238.08
Switching capacity (Gbps) 320
Total system ports 8x 10 GE copper + 8x 10 GE SFP+ plus 1x GE OOB management
Network ports 8x 10 GE
Uplink ports 8x 10 GE SFP+
Packet buffer 2 MB
Feature Description
Capacity in mpps (64-byte packets) 238.08
Switching capacity (Gbps) 320
Total system ports 8x 10 GE copper + 8x 10 GE SFP+ plus 1x GE OOB management
Network ports 8x 10 GE
Uplink ports 8x 10 GE SFP+
Packet buffer 2 MB
Unit dimensions (W x H x D) 440 x 44 x 350 mm (17.3 x 1.7 x 13.78 in)
Layer 3
IPv4 routing
  • Wirespeed routing of IPv4 packets
  • Up to 7,168 routes and up to 256 IP interfaces
Wirespeed IPv6 static routing Up to 1,792 routes and up to 256 IPv6 interfaces
Layer 3 interface Configuration of Layer 3 interface on physical port, LAG, VLAN interface, or loopback interface
Security
SSH SSH is a secure replacement for Telnet traffic. SCP also uses SSH. SSH versions 1 and 2 are supported
SSL Secure Sockets Layer (SSL) encrypts all HTTPS traffic, allowing secure access to the browser-based management GUI in the switch
Quality of service
Priority levels 8 hardware queues
Scheduling Strict priority and Weighted Round-Robin (WRR)
Class of service
  • Port based; 802.1p VLAN priority based; IPv4/v6 IP precedence/ToS/DSCP based; DiffServ; classification and remarking ACLs, trusted QoS
  • Queue assignment based on Differentiated Services Code Point (DSCP) and class of service (802.1p/CoS)
Management
Web user interface
  • Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS).
  • Supports simple and advanced mode, configuration, wizards, customizable dashboard, system maintenance, monitoring, online help, and universal search
Smart Network Application (SNA) An innovative network-level monitoring and management tool embedded in Cisco 250 to 550X Series switches. It can discover network topology, display link status, monitor events, apply configurations, and upgrade software images across multiple switches in the network
SNMP SNMP versions 1, 2c, and 3 with support for traps, and SNMP v3 User-based Security Model (USM)
RMON Embedded RMON software agent supports 4 RMON groups (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis
IPv4 and IPv6 dual stack Coexistence of both protocol stacks to ease migration
Firmware upgrade
  • Web browser upgrade (HTTP/HTTPS) and TFTP and SCP
  • Upgrade can be initiated through console port as well
  • Dual images for resilient firmware upgrades
Product specifications
Console port Cisco Standard RJ-45 console port
OOB management port Dedicated Gigabit management port for out-of-band management on SG550XG and SX550X models
RPS RPS connector
USB slot USB Type-A slot on the front panel of the switch for easy file and image management
Buttons Reset button
Cabling type Unshielded Twisted Pair (UTP) Category 5 or better; fiber options (SMF and MMF); coaxial SFP+
LEDs System, master, fan, RPS, stack ID, link/speed per port
Flash 256 MB
CPU
  • 1.3 GHz (dual-core) ARM for SX550X models
  • 800 MHz (dual-core) ARM for all other models
CPU memory 512 MB
Power 100 – 240V 47 – 63 Hz, internal, universal
Certification UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A
Operating temperature 32° to 122°F (0° to 50°C)
Storage temperature -4° to 158°F (-20° to 70°C)
Operating humidity 10% to 90%, relative, non-condensing
Storage humidity 10% to 90%, relative, non-condensing
