Cisco CBS350-16XTS Kenya



Cisco CBS350-16XTS Kenya

The Cisco CBS350-16XTS Kenya is a portfolio of affordable wireless access points, switches and routers designed and built for Small Business. Managed through Cisco Business Dashboard and mobile app, the portfolio provides a simple and reliable experience.

Category:

Description

Cisco CBS350-16XTS Network Switch Kenya

The Cisco CBS350-16XTS Kenya is a portfolio of affordable wireless access points, switches and routers designed and built for Small Business. Managed through Cisco Business Dashboard and mobile app, the portfolio provides a simple and reliable experience. Cisco Business Dashboard simplifies traditional challenges in deploying and managing business networks by automating the deployment, monitoring and lifecycle management of the network. The Cisco CBS350-16XTS Kenya switch, part of the Cisco Business line of network solutions, is a portfolio of affordable managed switches that provides a critical building block for any small office network. Intuitive dashboard simplifies network setup, and advanced features accelerate digital transformation, while pervasive security protects business critical transactions. The Cisco CBS350-16XTS Kenya provides the ideal combination of affordability and capabilities for small office and helps you create a more efficient, better-connected workforce.

The Cisco CBS350-16XTS Kenya switch expand your business’s or data center’s network capacity to support high-bandwidth devices such as computers, network attached storage enclosures, servers, and more. The Cisco CBS350-16XTS Kenya is 16-Port 10G RJ45/SFP+ Managed Switch. This managed rackmount switch features eight 10G copper RJ45 Ethernet ports alongside eight dedicated 10G SFP+ ports for high-speed fiber connections. There is also an RJ45 Ethernet management port. Its extensive Layer 2 and Layer 3 features include secure connections, clear communications, and link aggregation to create up to eight groups of 16 ports for multi-Gig connections to compatible devices. Its 320 Gb/s switching capacity and 238.08 Mpps forwarding rate help to ensure smooth and reliable data transfers. Use the Cisco Business Dashboard portal and mobile app to configure and monitor the Cisco CBS350-16XTS Kenya and its connected devices. Its triple-fan design helps to maintain optimal temperatures as it works quietly in the background.

Features

Reliable Performance

Cisco CBS350-16XTS Kenya switch is equipped with an 800 MHz ARM processor and 512MB of memory, which work to deliver smooth and reliable data transfers with a 320 Gb/s switching capacity and 238.08 Mpps forwarding rate.

10 Gigabit Speeds

The Cisco CBS350-16XTS Kenya switch features eight copper 10G RJ45 ports and eight 10G SFP+ fiber ports, supporting high-bandwidth backups, file transfers, and other applications.

Extensive Security

  • Cisco CBS350-16XTS Kenya has support for features such as IEEE 802.1x and port security limit access to specific segments of your network while web-based authentication provides a consistent interface to all types of host devices and operating systems.
  • Advanced defense mechanisms, such as dynamic Address Resolution Protocol (ARP) inspection, IP Source Guard, and Dynamic Host Configuration Protocol (DHCP) snooping, help to detect and block network attacks. When combined, these protocols may be referred to as IP-MAC port binding (IPMB).
  • The IPv6 First Hop Security suite includes ND inspection, RA guard, DHCPv6 guard, and neighbor binding integrity check to protect your IPv6 network against a range of address spoofing and man-in-the-middle attacks.

IPv6 Support

The Cisco CBS350-16XTS Kenya switch supports allows you to evolve your network using the IPv6 standard while remaining compatible the previous-generation IPv4 networks.

Layer 3 Static Routing

Dynamic Layer 3 routing features include the ability to segment your network into separate workgroups and communicate across VLANs without degrading application performance, which allows you to manage your switch’s internal routing and dedicate your router to external traffic and security to help your network run efficiently.

True Stacking

Reduce the complexity of your network while enhancing your control over a growing network by configuring, managing, and troubleshooting all your switches in a stack as a single unit using a single IP address. True stacking also provides other benefits through features such as cross-stack QoS, VLANs, LAGs, and port mirroring.

Compact Design

With a sleek and compact 1 RU design, the Cisco CBS350-16XTS Kenya can fit into wiring closets and other installations within retail stores, offices, and other businesses.

Energy Efficient

Cisco CBS350-16XTS Kenya has support for the Energy Efficient Ethernet (IEEE 802.3az) standard helps to significantly reduce energy consumption by monitoring the amount of traffic an active link receives and putting it to sleep during down times.

Specifications

Interfaces
Ports
  • 8 x 10Gb Ethernet (RJ45)
  • 8 x 10Gb SFP+
  • 1 x Ethernet (RJ45) (Console)
  • 1 x USB Type-A
Protocols
Layer Services Supported Layer 2 Support, Layer 3 Support
Supported Protocols
  • Head-of-Line (HOL) Blocking’
  • IGMP Snooping
  • IPv4
  • IPv6
  • Link Aggregation
  • MAC Filtering
  • Port Mirroring
  • RADIUS
  • SNMPv1
  • SNMPv2c
  • SNMPv3
Queuing Strict Priority, Weighted Round Robin (WRR)
Jumbo Frames Support 9000 Bytes
MAC Address Table Size 16K
Multicast Groups 2000
VLAN IDs 4094
Security
Security Features
  • DoS Attack Prevention
  • RADIUS Authentication
  • Storm Control
Access Control List 1024
IP Interfaces 128
Static Routes 990
SNMP Support 1, 2c, 3
Standards
RFC RFC 4330
Supported IEEE Standards 802.1ab, 802.1d, 802.1q/p, 802.1s, 802.1w, 802.1x, 802.3, 802.3ab, 802.3ad, 802.3an, 802.3az, 802.3u, 802.3x, 802.3z
Performance
Forwarding Rate 238.08 Mpps
Switching Bandwidth 320 Gb/s
Priority Queues 8
Packet Buffer 3 MB
Computer
Flash Memory 256 MB
Processor 800 MHz ARM
Memory 512 MB
OS Compatibility
  • Windows
  • macOS
  • Linux
Electrical
Power Draw 57.7 W (Max)
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Supply Type Internal
Environmental
Operating Temperature 32 to 122°F / 0 to 50°C
Operating Humidity 10 to 90%
Storage Temperature -13 to 158°F / -25 to 70°C
Storage Humidity 10 to 90%
Noise Level 39.1 dB
General
Cooling System Fan
Mean Time Between Failures (MTBF) 798,504 Hours
Indicator Lights Link/Activity, Speed, System
Rack Form Factor 1 RU
Dimensions 17.3 x 10.1 x 1.7″ / 440 x 257 x 44 mm
Weight 8.36 lb / 3.79 kg
