Cisco Catalyst9500-32QC Kenya



Cisco Catalyst9500-32QC Kenya

The Cisco Catalyst9500-32QC Kenya comes with a 4-core x86, 2.4-GHz CPU, 16-GB DDR4 memory, and 16-GB internal storage.

Category:

Description

Cisco Catalyst9500-32QC Network Switch Kenya

The Cisco Catalyst9500-32QC Kenya Ethernet Switch is part of the Cisco Catalyst 9500 Series switches and are among the next generation of enterprise-class core and aggregation layer switches, supporting full programmability and serviceability. Based on an x86 CPU, the Cisco Catalyst 9500 Series is Cisco’s lead purpose-built fixed core and aggregation enterprise switching platform, built for security, IoT, and cloud. The  comes with a 4-core x86, 2.4-GHz CPU, 16-GB DDR4 memory, and 16-GB internal storage.

Features

  • Simplified device deployment
  • Unified management of wired and wireless networks
  • Network virtualization and segmentation
  • Group-based policies
  • Context-based analytics
  • Up to 6.4-Tbps switching capacity with up to 2 Bpps of forwarding performance
  • Platinum-rated AC/DC power supplies
  • Up to 512,000 Flexible NetFlow (FNF) entries in hardware
  • Intel® 2.4-GHz x86 CPU with up to 120 GB of USB 3.0 or up to 960 GB of SATA SSD storage for container-based application hosting
  • SD-Access for policy-based automation from edge to cloud

Technical Specs

Product Name 9500 32 Port 40/100G Only Advantage
Manufacturer Part Number C9500-32QC-A
Product Type Layer 3 Switch
Manageable Yes
Ethernet Technology 40 Gigabit Ethernet
Number of Total Expansion Slots 32
Product Family Catalyst 9500
Media Type Supported Optical Fiber
Redundant Power Supply Supported Yes
Expansion Slot Type QSFP+
Form Factor Rack-mountable
Power Source Power Supply
Layer Supported 3
Compatible Rack Unit 1U
Modular Yes
Shared SFP Slot No
Port / Expansion Slot Details 32 x 40 Gigabit Ethernet Expansion Slot
Height 1.7″
Width 17.5″
Depth 18″
Product Series 9500
Product Model C9500-32QC
Network Technology 40GBase-X
Product Line Catalyst
