Fortinet FG-3980E Kenya



Fortinet FG-3980E Kenya

The Fortinet FortiGate 3980E delivers high performance threat protection for mid-sized to large enterprises and service providers, with the flexibility to be deployed at the Internet or cloud edge, in the data center core or internal segments. The multiple high-speed interfaces, high port density, industry-leading security efficacy and high throughput of the 3900E series keeps your network connected and secure.

Category:

Description

Fortinet FortiGate-3980E Nairobi

The Fortinet FortiGate-3900E Series in Nairobi, Kenya delivers extremely high performance and excellent next generation firewall capabilities to various large-sized firms and service providers. It uses its multiple high speed interfaces, high port density, and high throughput to enhance your network security. It incorporates the use of Fortinet’s leading security protocols such as IPS, SSL inspection, and advanced threat protection to improve your network’s general performance.  The Fortinet’s Security-Driven Networking approach provides tight integration of the network to the new generation of security.

Fortinet Firewall in Nairobi uses Custom SPU processors to deliver the power required to detect malicious content at multi-Gigabit speeds. Other security technologies cannot protect against today’s wide range of content- and connection-based threats because they rely on general-purpose CPUs, causing a dangerous performance gap. SPU processors therefore have been built to provide the performance needed to block emerging threats, meet rigorous third-party certifications, and ensure that your network security solution does not become a network bottleneck.

Fortinet FG-3980E Features.

  • Security :

    • Fortinet FG-3980E identifies thousands of applications inside network traffic for deep inspection and granular policy enforcement, then protects the network system against malware, exploits, and malicious websites in both encrypted and non-encrypted traffic. It also detects known attacks using continuous threat intelligence from AI-powered FortiGuard Labs security services. The Fortinet FG-3980E proactively blocks unknown sophisticated attacks in real-time with the Fortinet Security Fabric integrated AI-powered FortiSandbox.
  • Performance

    • Fortinet FG-3980E is built for Innovation using Fortinet’s purpose-built security processors (SPU) to deliver the industry’s best threat protection performance and ultra-low latency. It provides industry-leading performance and protection for SSL encrypted traffic including the first firewall vendor to provide TLS 1.3 deep inspection.
  • Certification

    • Fortinet FG-3980E has been independently tested and validated for best security effectiveness and performance. It has received unparalleled third-party certifications from NSS Labs, ICSA, Virus Bulletin, and AV Comparatives.
  • Networking

    • Fortinet FG-3980E incorporates Application aware routing with in-built SD-WAN capabilities to achieve consistent application performance and the best user experience. It has built-in advanced routing capabilities which deliver high performance with encrypted IPSEC tunnels at scale.
  • Management

    • Fortinet FG-3980E includes a management console that is effective and simple to use, which provides a comprehensive network of automation & visibility. It provides Zero Touch Provisioning leveraging Single Pane of Glass Management powered by the Fabric Management Center, and uses a set of predefined compliance checklists analyze the deployment and highlight best practices to improve the overall security posture.
  • Security Fabric

    • Fortinet FG-3980E enables Fortinet and Fabric-ready partners’ products to provide broader visibility, integrated end-to-end detection, threat intelligence sharing, and automated remediation. It automatically builds Network Topology visualizations which discover IoT devices and provide complete visibility into Fortinet and Fabric-ready partner products.
  • Next Generation Firewall (NGFW)

    • Fortinet FG-3980E reduces complexity and maximizes your ROI by integrating threat protection security capabilities into a single high performance network security appliance, powered by Fortinet’s Security Processing Unit (SPU). It offers full visibility into users, devices, applications across the entire attack surface and consistent security policy enforcement irrespective of asset location. The robust firewall protects your network system against network exploitable vulnerabilities with Industry validated IPS , resulting in security effectiveness, low latency and optimized network performance. It automatically block threats on decrypted traffic using the Industry’s highest SSL inspection performance, including the latest TLS 1.3 standard with mandated ciphers, and also proactively block newly discovered sophisticated attacks in real-time with AI-powered FortiGuard Labs and advanced threat protection services included in the Fortinet Security Fabric.
  • IPS

    • Fortinet FG-3980E uses its purpose-built security processors delivering industry validated IPS performance with high throughput and low latency. It deploys virtual patches at the network level to protect against network exploitable vulnerabilities and optimize network protection time. Deep packet inspection at wire speeds offers unparalleled threat visibility into network traffic including traffic encrypted with the latest TLS 1.3.
  • Segmentation

    • Fortinet FG – 3980E boasts of a segmentation feature that adapts to any network topology, delivering end-to-end security from the branch level to data centers and extending to multiple clouds. Segmentation reduces security risks by improving network visibility from the components of the Fortinet Security Fabric, which adapt access permissions to current levels of trust and enforce access control effectively and efficiently. It also delivers defense in depth security powered by high-performance L7 inspection and remediation by Fortinet’s SPU, while delivering third party validated TCO of per protected Mbps, and also protects critical business applications and helps implement any compliance requirements without network redesigns.
  • Mobile Security for 4G, 5G, and IOT

    • Fortinet FG-3980E is equipped with standard features including SPU acceleration, high performance CGNAT and IPv6 migration option including: NAT44, NAT444, NAT64/DNS64, NAT46 for 4G Gi/sGi and 5G N6 connectivity and security. It also boasts of RAN Access Security with highly scalable and best performing IPsec aggregation and control security gateway (SecGW). It has user plane security enabled by full Threat Protection and visibility into GTP-U inspection, and supports 4G and 5G security for user and data plane traffic including SCTP, GTP-U and SIP that provides protection against attacks. It is also packed with high-speed interfaces to enable deployment flexibility.
  • Secure Web Gateway (SWG)

    • Fortinet FG- 3980E allows for secure web access from both internal and external risks, even for encrypted traffic at high performance, thus offering enhanced user experience with dynamic web and video caching. It also blocks and controls web access based on user or user groups across URL’s and domains. The Firewall prevents data loss and discovers user activity to known and unknown cloud applications. In addition, it blocks DNS requests against malicious domains using multi-layered advanced protection against zero-day malware threats delivered over the web.

FORTINET FORTIGATE – 3980E SPECS

POWER DEVICE

  • Nominal Voltage
    AC 120/230 V
  • Frequency Required
    50/60 Hz
  • Power Consumption Operational
    2350 Watt

INTERFACE PROVIDED

  • Qty
    1, 10, 16, 2

CHASSIS

  • Built-in Devices
    LED panel

NETWORKING

  • Remote Management Protocol
    CLI, HTTP
  • Status Indicators
    HA, alarm, link/activity, power, status
  • Network / Transport Protocol
    IPSec, SCTP, TCP/IP, UDP/IP
  • Features
    CAPWAP support, Carrier-Class Firewall (CCFW), Data Center Firewall (DCFW), High Availability, IPSec Virtual Private Network (VPN), IPv4 support, IPv6 support, Intrusion Prevention System (IPS), SSL inspection, VPN support, application filtering, firewall protection, hot swappable power supply, manageable, traffic shaping, web threat protection
  • Data Link Protocol
    10 Gigabit Ethernet, 100 Gigabit Ethernet, 40 Gigabit Ethernet, Gigabit Ethernet
  • Capacity
    Client to gateway IPSec VPN tunnels: 200000
    Gateway to gateway IPSec VPN Tunnels: 40000
    Concurrent TCP sessions: 160000000
    New TCP sessions per second: 550000
    Firewall policies: 200000
    Virtual domains: 500
    Number of FortiClient devices: 20000
    Number of FortiToken devices: 5000
    Concurrent SSL VPN users: 30000
    Number of FortiAP devices: 4096
  • Connectivity Technology
    wired

MISCELLANEOUS

  • Encryption Algorithm
    128-bit AES, 256-bit AES, 256-bit SHA, SSL, TLS 1.2
  • Height (Rack Units)
    5 m

POWER

  • Power Redundancy
    yes

SOFTWARE / SYSTEM REQUIREMENTS

  • Type
    FortiOS

ENVIRONMENTAL PARAMETERS

  • Min Operating Temperature
    32 °F
  • Max Operating Temperature
    104 °F

HEADER

  • Brand
    Fortinet
  • Product Line
    Fortinet FortiGate
  • Model
    3980E
  • Packaged Quantity
    1
  • Compatibility
    PC

DIMENSIONS & WEIGHT

  • Width
    17.2 in
  • Depth
    27.4 in
  • Height
    8.7 in
  • Weight
    106.26 lbs

Interfaces

  • Console Port
  • USB Port
  • 2x GE RJ45 Management Ports
  • 16x 1/10 G SFP/SFP Slots
  • 10x 40/100 GE QSFP /QSFP28 Slots
